iFlight 2RAW Helion 10-Inch Frame Kit

  • $299.99
    Unit price per


+ -

HELION - The Ultra Range flagship by 2RAW and iFlight

This frame kit was built to redefine Long-Range and take it to a whole new level and to meet the rising demands for more range, and more flight time while maintaining enough weight, to have excellent stability in even the most windy conditions. With a size of 10 inches, Helion is not only capable of effectively carrying large (Recommended, 4500mAh Lipo and above) batteries while ensuring great efficiency but also has a lot of power. You will recover better when diving and have overall more control than traditional long-range drones. Its unique aerodynamic shell allows for easy maintenance while protecting the cores of the power train when in use. Helion’s distinct frame design was scientifically optimized to balance perfectly between stability, weight, and rigidity.

Features:

Aero-Shell

The unique aerodynamic shell allows for easy maintenance while protecting the cores of the power train. Users can simply open and close the shell when working on the drone. The idea was to protect the inside but give people full access when maintenance work is being performed on the drone.

Innovative A-Frame for Maximum Performance

The frame was scientifically optimised and tested over months to find the balance between stability and weight. The A-Frame design minimizes vibrations as well as torsion, one of the biggest problems with larger drones.

Specifications:

  • Product Name: Helion 10 Frame Kit
  • Geometry: A-Frame
  • Frame wheelbase: 418mm
  • Frame Dimension: L324*W264*H63 mm
  • Frame Body Dimension: 63mm
  • Arm Thickness: 8mm
  • Bottom Plate Thickness: 3mm
  • Upper Plate Thickness: 3mm
  • Max Flight Stack Height: 25mm
  • Max VTX Height: 22mm
  • Flight Stack Mounting: 30.5*30.5/Φ3mm
  • VTX Mounting: 25.5*25.5/Φ1.6mm
  • Motor Mounting: 19*19-φ3mm
  • Weight: 540±20g

Includes:
1x iFlight and 2RAW Helion 10-Inch Frame Kit
1x TPU Set
4x Motor Wire Shield Tube
2x Battery Anti-Slip Pad
3x Battery Strap (20*300mm)
1x Screw Bag
